XG-SFP-SR-MM850
10GBASE-SR SFP+ 850-nm 300-m DOM Duplex LC MMF Optical Transceiver Module
- Max. power consumption 1.5 W
- Hot pluggable SFP+ MSA compliant
- Digital optical monitoring capability for strong diagnostic capabilities
- Compliant with IEEE 802.3z Gigabit Ethernet
- Class 1 Laser safety and RoHS compliant
TECHNICAL SPECIFICATIONS
| Details | |
|---|---|
| Waveleng th (nm) | 850 |
| DDM | Yes |
| Optical Fiber Type | SMF |
| Intensity of Transmitted Light/dBm | Min -5, Max -1 |
| Intensity of Received Light/dBm | Min -7.5, Max 0.5 |
| Connector Type | LC |
| Optical Fiber Type | MMF |
| Core Specification (um) | 62.5/125 / 50/125 |
| Modal Bandwidth (MHz.km) | 200(OM1) 160 / 2000(OM3) |
| Maximum Cabling Distance | 33 m 26 m / 300 m |
