XG-SFP-SR-MM850
May 13, 2022
XG-SFP-LR-SM1310
10GBASE-LR SFP+ 1310-nm 10-km DOM Duplex LC SMF Optical Transceiver Module
- Max. power consumption 1.5 W
- Hot pluggable SFP+ MSA compliant
- Digital optical monitoring capability for strong diagnostic capabilities
- Compliant with IEEE 802.3z Gigabit Ethernet
- Class 1 Laser safety and RoHS compliant
TECHNICAL SPECIFICATIONS
| Details | |
|---|---|
| Waveleng th (nm) | 1310 |
| DDM | Yes |
| Optical Fiber Type | SMF |
| Intensity of Transmitted Light/dBm | Min -8.2, Max 0.5 |
| Intensity of Received Light/dBm | Min -14.4, Max 0.5 |
| Connector Type | LC |
| Optical Fiber Type | SMF |
| Core Specification (um) | 9/125 |
| Modal Bandwidth (MHz.km) | N/A |
| Maximum Cabling Distance | 10KM |
