XE5-8 Wi-Fi 6E
802.11ax Tri-Band 8×8/4×4 High-density Access Point
- The XE5-8 is a five-radio Wi-Fi 6/6E 8×8/4×4 access point (AP) designed to deliver high-density, future-proof performance for building next generation wireless networks.
- With five user servicing radios, the XE5-8 delivers the highest density Wi-Fi 6 solution in the industry.
- Wi-Fi 6E support extends the capacity of Wi-Fi into the 6 GHz band, more than tripling the wireless spectrum available.
TECHNICAL SPECIFICATIONS
| Radios | Two: 4×4 5/6 GHz 802.11a/n/ac/ax, SW configurable to 5 or 6GHz operation Two: 4×4 5 GHz 802.11a/n/ac/ax, SW configurable to one 8×8 radio One: 4×4 2.4 GHz 802.11 b/g/n/ax BLE 4.1 |
| Ports | 2 x IEEE 10/100/1000/2500/5000 Mbps Ethernet 1 x USB 3.0 |
| Antenna | 6 GHz: 5.82 dBi, Omni 5 GHz: 5.61 dBi, Omni 2.4 GHz: 4.58 dBi, Omni |
| Power | Max 59W 802.3bt powered device |
| Dimensions | 300 mm x 300 x 58 mm (without bracket) (11.81 in x 11.81 x 2.28 in ) |
| Weight | 1.8 kg (3.97 lbs) |
| Wi-Fi Protocols | VHT MCS rates, 16/64/256/1024/4096-QAM, 20/40/80/160 MHz |
