TOM1000-BHTB6R2040
6-Port Layer 2 Industrial Switch
- Up to 20Gbps backplane bandwidth
- Support network management
- Lightning protection: power supply port ±4KV, RJ45 port ±4KV
- Fanless design, wide working temperature and quiet operation
TECHNICAL SPECIFICATIONS
| Details | |
|---|---|
| Fixed Service Port | 2 x 100/1000BaseX SFP ports (SFP module not included) 4 x 10/100/1000BaseT ports |
| Protection Class | IP40 |
| Forwarding/Exchange rate | 148,800 pps /100M port 1,488,000 pps/1000M port |
| MAC address table | 8000 |
| Operating temperature | -40°C ~ +75 ° C. |
| Power Consumption | 9.6 ~ 60VDC & 18 ~ 30VAC, dual redundant inputs |
| Dimensions (W x D x H) (mm) | 43.5mm x 110mm x 105mm |
| Unit Weight | <0.6kg |
