RG-CS86-48MG4VS2QXS-UPD
48-Port Multi-GE Switch with Cloud Management, Full 1GE/2.5GE/5GE Access with PoE/PoE+/PoE++
-
48 x 100/1000/2.5G/5GBASE-T ports for access, 4 x 10GE/25GE SFP28 ports and 2 x 40GE QSFP+ ports for uplink, meeting high-bandwidth campus network demands
- Hardware-level multi-protection, ensuring service continuity
- VSU, realizing flexible networking and high performance
- Network security policies and real-time monitoring, enhancing network robustness
- Intelligent speed regulation and auto sleeping, reducing energy consumption and noise
- Diverse network management modes, enabling simple maintenance
TECHNICAL SPECIFICATIONS
| Details | |
|---|---|
| Fixed Service Port | 48 x 100M/1000M/2.5GE/5GE electrical ports with auto-negotiation, 4 x 10GE/25GE SFP28 ports + 2 x 40GE QSFP + ports |
| Switching capacity | 840 Gbps/2.56 Tbps |
| Forwarding rate | Up to 625 Mpps |
| Fixed management ports |
1 x MGMT port, 1 x console port, and 1 x USB port
|
| Power Consumption | Without PoE: < 240 W (Total power consumption of all modules), Full PoE load: < 1600 W |
| Dimensions (W x D x H) (mm) | 442 × 220 × 43.6 mm (17.40 × 29.92 × 6.89 in.) , 1 RU |
| Unit Weight | 6.11 kg (13.47 lbs) |
