POWERBEAM-5AC-GEN2
airMAX PowerBeam AC, 5 Ghz, Bridge
- Highly Efficient Antenna Beam Performance
- Up to 450+ Mbps Throughput
- Dedicated Wi-Fi Radio for Management
TECHNICAL SPECIFICATIONS
| Details | |
|---|---|
| Dimensions | 420 x 420 x 230mm (16.54 x 16.54 x 9.06″) |
| Weight | 2.22 kg (4.89 lb) |
| Gain | 25 dBi |
| Networking Interface | (1) 10/100/1000 Ethernet Port |
| Processor | MIPS 74Kc |
| Enclosure Characteristics | Antenna Feed: Outdoor UV Stabilized Plastic Dish Reflector: Powder-Coated SPCC |
| Max. Power Consumption | 8.5W |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter (Included) |
| Power Method | Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Wind Loading | 380 N @ 200 km/h (85.4lbf @ 125 mph) |
| Wind Survivability | 200 km/h (125 mph) |
