CCR1009-7G-1C-1S+
1U rackmount, 7x Gigabit Ethernet, 1x Combo port (SFP or Gigabit Ethernet), 1xSFP+ cage, 9 cores x 1.2GHz CPU, 2GB RAM, LCD panel, Dual Power supplies, SmartCard slot, RouterOS L6.
- No switch-chip – Each Ethernet port is directly connected to the CPU, removing the previous shared 1 Gbps limitation and maximizing CPU processing potential.
- Combo-port – One 1 Gbps interface with two physical options (SFP cage + Gigabit Ethernet), switchable in RouterOS, with hardware failover on disconnect.
- 100 Mbps SFP support – Supports 100BASE-LX, 100BASE-SX, 100BASE-BX fiber modules, and standard 1.25 G SFP modules.
- Higher throughput – Direct CPU connections allow greater overall throughput.
TECHNICAL SPECIFICATIONS
| Details | |
|---|---|
| CPU | TLR4-00980 |
| Operating System | RouterOS |
| Size of RAM | 2 GB |
| Storage size | 128 MB |
| POWERING | |
| Max power consumption | 39 W |
| ETHERNET | |
| 10/100/1000 Ethernet ports | 7 |
| FIBER | |
| SFP+ ports | 1 |
