AIRMAX-5G17-90
airMAX Sector 5 GHz, 90º, 17 dBi Antenna
- High Performance, Long Range
- Seamlessly Integrates with Rocket® Radio
- Excellent Cross-Polarization Isolation
This product is already in your quote request list.
TECHNICAL SPECIFICATIONS
| Details | |
|---|
| Dimensions | 367 x 63 x 41 |
| Weight | 1.1 kg |
| Frequency Range | 4.90 – 5.85 GHz |
| Gain | 16.1 – 17.1 dBi |
| HPOL Beamwidth | 72° (6 dB) |
| VPOL Beamwidth | 93° (6 dB) |
| Electrical Beamwidth | 8° |
| Electrical Downtilt | 4° |
| Max. VSWR | 1.5:1 |
| Wind Survivability | 125 mph |
| Wind Loading | 6 lbf @100 mph |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 22 dB Min. |
