ROCKETDISH-5G34
airMAX RocketDish, 5 GHz, 34 dBi Antenna
- Powerful Performance for Long-Range Links
- Robust Design and Construction for Outdoor Use
- Seamless Integration with Rocket Radios
TECHNICAL SPECIFICATIONS
| Details | |
|---|---|
| Dimensions | 1050 x 1050 x 421 mm (41.34 x 41.34 x 16.57″) |
| Weight | 13.5 kg (29.76 lb) |
| Frequency Range | 4.9 – 5.8 GHz |
| Gain | 4.9 GHz: 30 dBi 5 – 5.8 GHz: 34 dBi |
| HPOL Beamwidth | 3° (3 dB) |
| VPOL Beamwidth | 3° (3 dB) |
| F/B Ratio | 42 dB |
| Max. VSWR | 1.4:1 |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 1,779 N @ 200 km/h (400 lbf @ 125 mph) |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 35 dB Min. |
