RG-NBS5100-24GT4SFP-P
28-Port Gigabit Layer 3 PoE Switch
- 28-Port gigabit Layer 3 managed PoE switch, 4 SFP uplink
- Enterprise-class Quality Ensures High Performance
- 6KV surge protection reduces the possibility of port damage
- Multiple Security Policies Protect Your Network
- Lifetime management on Ruijie Cloud at anytime anywhere
TECHNICAL SPECIFICATIONS
| Details | |
|---|---|
| Switching capacity | 56 Gbps |
| Package forwarding rate | 42 Mpps |
| Ports | 24 x 10/100/1000Base-T PoE+ ports, 4 SFP uplink |
| Power Consumption | ≤ 42.48 (with no PoE load)
≤ 431.86W (with full PoE load) |
| Input power supply | Single fixed power supply |
| Dimensions | 440 mm x 357.6 mm x 43.6 mm |
| Weight | 4.5kg |
| Management | eWeb, Ruijie Cloud, Ruijie Reyee App, SNMPv1, v2c, and v3 |
