GCC6010 Series
- All-in-one solution that includes a VPN router, next-generation firewall, IP PBX, and network switch or Wi-Fi access point
- Built-in IP PBX provides voice & video communications with advanced collaboration features (PBX Upgrade options available)
- Built-in firewall provides anti-virus, layer 3-7 IDS/IPS, DPI, SSL detection, and more
- Built-in VPN router supports 2.5Gbps to allow easy remote access
- Managed through the cloud (GDMS), mobile app, local WEB UI, SSH, and SNMP
TECHNICAL SPECIFICATIONS
| Details | |
|---|---|
| Dimensions |
280 x 180 x 44 mm
|
| Weight | 1200g |
| Throughput | 2.5Gbps |
| Fixed Port(s) | 2 x 2.5 Gigabit SFP ports 10 x Gigabit Ethernet ports *3x Fixed WAN |
| Clients | Up to 150 GWN APs; Up to 500 Clients |
| Network Protocol | IPv4, IPv6, IEEE802.1q ,IEEE 802.1p, IEEE802.1x, IEEE802.3, IEEE 802.3u, IEEE 802.3x,IEEE802.3ab |
| Network Management | Grandstream Device Management System (GDMS), Local Web GUI, SSH, and SNMP (v1/ v2c/v3)) |
| Power Supply | 100-240VAC 50-60Hz |
| Maximum PoE Wattage | 36W |
| RAM | 2GB RAM |
| Flash | 32GB eMMC Flash |
