EDGEROUTER-12
High-performance router with a built-in Layer 2 switch, (10) Gigabit RJ45 ports, and (2) SFP ports.
- Sophisticated Routing Features
- Advanced Security, Monitoring, and Management
- High-Performance Gigabit Ports
TECHNICAL SPECIFICATIONS
| Details | |
|---|---|
| Dimensions | 268.1 x 136.5 x 31.1 mm (10.55 x 5.37 x 1.22″) |
| Weight | 700 g (1.54 lb) |
| Max. Power Consumption | 20W (Excludes PoE Output) |
| Power Supply | External AC/DC Adapter |
| Power Method | External AC/DC Power Adapter, 24W (24V, 1A) (Included) 24V Passive PoE |
| Processor | 4-Core 1 GHz MIPS64 |
| System Memory | 1 GB DDR3 RAM |
| On-Board Flash Storage | 4 GB eMMC, 8 MB SPI NOR |
| Management Interfaces | (1) RJ45 Serial Port, (10) Ethernet Ports (Default Port 0) (10) 10/100/1000 RJ45 Ports |
| Networking Interfaces | Port 0 Supports PoE IN; Port 9 Supports PoE Out (2) 1 Gbps SFP Ports |
