EDGEROUTER-X
May 9, 2022
AIRMAX-OMNI-5G10
May 9, 2022
AIRMAX-OMNI-5G13
airMAX Omni 5 GHz, 13 dBi Antenna
- High Performance, Long Range
- Seamlessly Integrates with Rocket® Radio
- 360° Coverage
TECHNICAL SPECIFICATIONS
| Details | |
|---|---|
| Dimensions | 799 x 90 x 65 mm (31.46 x 3.54 x 2.56″) |
| Weight | 0.82 kg (1.81 lb) |
| Frequency Range | 5.45 – 5.85 GHz |
| Gain | 13 dBi |
| Elevation Beamwidth | 7° |
| Max VSWR | 1.5:1 |
| Downtilt | 2° |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 84.52 N @ 200 km/h (19 lbf @ 125 mph) |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 25 dB min. |
