AIRMAX-5G20-90
airMAX Sector 5 GHz, 90º, 20 dBi Antenna
- High Performance, Long Range
- Seamlessly Integrates with Rocket® Radio
- Excellent Cross-Polarization Isolation
This product is already in your quote request list.
TECHNICAL SPECIFICATIONS
| Details | |
|---|
| Dimensions | 700 x 135 x 70 |
| Weight | 5.9 kg |
| Frequency Range | 5.15 – 5.85 GHz |
| Gain | 19.4 – 20.3 dBi |
| HPOL Beamwidth | 91° (6 dB) |
| VPOL Beamwidth | 85° (6 dB) |
| Electrical Beamwidth | 4° |
| Electrical Downtilt | 2° |
| Max. VSWR | 1.5:1 |
| Wind Survivability | 125 mph |
| Wind Loading | 26 lbf @ 100 mph |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 28 dB min. |
